Five Parameter Water Quality Analyzer designed for measuring pH, temperature, dissolved oxygen, conductivity, and turbidity. This integrated system combines multiple measurement capabilities into one unit, ensuring enhanced efficiency and ease of use for all operators. It features direct connectivity with smart electrodes and multi-parameter electrodes, allowing for seamless integration. The K100S provides a real-time display of measurement values and electrode status, facilitating quick and accurate assessments. It is suitable for a variety of application scenarios, including surface water, municipal wastewater, industrial effluent, drinking water, and aquaculture, making it a reliable choice for comprehensive water quality monitoring.
|
Measurement Principle |
Light scattering method |
|
Measurement Range |
0 to 4000 NTU; automatic range switching (100, 500, 2000, 4000 NTU) |
|
Detection Standard |
HJ/T98-2003 |
|
Resolution |
0.01 NTU (depending on range) |
|
Repeatability |
±0.5% |
|
Accuracy |
±1% |
|
Linear Error |
±1% |
|
Zero Drift |
±0.5% |
|
Range Drift |
±1% |
|
MTBF |
≥720 h |
|
Enclosure Rating |
≥IP65 |
|
Measurement Frequency |
Once per hour |
|
Communication |
RS485 (Modbus RTU standard protocol) |
- The sensor utilizes digital modulation filtering technology to eliminate the effects of ambient light.
- The sensor uses an infrared LED light source, which has a long lifespan of up to 10 years.
