Five Parameter Water Quality Analyzer designed for measuring pH, temperature, dissolved oxygen, conductivity, and turbidity. This integrated system combines multiple measurement capabilities into a single unit, ensuring enhanced efficiency and ease of use for all operators. It features direct connectivity with smart electrodes and multi-parameter electrodes, allowing for seamless integration. The K100S provides a real-time display of measurement values and electrode status, facilitating quick and accurate assessments. It is suitable for a variety of application scenarios, including surface water, municipal wastewater, industrial effluent, drinking water, and aquaculture, making it a reliable choice for comprehensive water quality monitoring.
|
Measurement Principle |
Fluorescence method |
|
Measurement Range |
0 to 20.00 mg/L, adjustable |
|
Detection Standard |
HJ/T99-2003 |
|
Repeatability |
±0.1 mg/L |
|
Accuracy |
±0.2 mg/L |
|
Precision |
±0.5% |
|
Display Error |
±0.2 mg/L |
|
Resolution |
0.01 mg/L |
|
Zero Drift |
±0.1 mg/L |
|
Range Drift |
±0.1 mg/L |
|
Response Time |
< 45 seconds |
|
Temperature Compensation Accuracy |
±0.1 mg/L |
|
MTBF |
≥720 h |
|
Enclosure Rating |
≥IP65 |
|
Measurement Frequency |
Once per hour |
|
Communication |
RS485 (Modbus RTU standard protocol) |
|
Dimensions |
D 34 mm, L 205 mm, 3-meter cable (customizable) |
- The sensor exhibits several key characteristics, minimal drift, fast response time and short polarization time.
- The sensor does not require the replacement of the dissolved oxygen membrane and electrolyte.
- The sensor is insensitive to fouling and is minimally affected by flow rate.
- The sensor can be calibrated directly in the air, eliminating the need for zero-point calibration.
